61
3.8.1.7. TP Frequency
Select a specific transponder by using the buttons, or pressing
the OK ( ) button to view the drop-down list.
3.8.1.8. Positioner Setup
3.8.1.8.1. DiSEqC 1.2
This mode will allow you to set the antenna position for each satellite.
In order to use antenna positioner you must use a motor controlled by
DiSEqC 1.2 commands.
To move the antenna, select the desired satellite, transponder and step
size. Then select Move Dish and press the buttons to move
the antenna West or East. If you selected Continuous for the step size,
the antenna will move continuously until you press another key. Once
the antenna is positioned properly (maximum level in the quality meter),
select Command Mode and choose save. Press the OK ( ) button to
save the position. The position number will be displayed next to the
satellite name.
When you want to move the antenna to a saved satellite position, select
the satellite, choose Go To Position from the Command Mode and press
