3.2.2.2 Set Option Jumpers
If required, set the option jumpers to the required configuration.
These jumpers are shown as item "E" in
Figure 3.5.
The bold options in Table 3.3 show the factory preset settings.
Table 3.3 — BVOCA Jumper Settings
Table 3.4 — Tone Configuration Default Settings
JP # Status Option
J1 Select Normally Open / Closed Relay contacts
J2 Must Be
Fitted
Reset controlled by Tone Configuration
J3 Fitted Audio Self Test Enabled
J3 Not Fitted Audio Self Test controlled by Tone Configuration
J4 Fitted Auto PTT Disabled
J4 Not Fitted Auto PTT controlled by Tone Configuration
J5 Fitted Calls always allowed
J5 Not Fitted Calls controlled by Tone Configuration
J6 Fitted Inhibit "Inactive" message
J6 Not Fitted "Inactive" message controlled by Tone
Configuration
JP # Option
J2 Reset by either "Button Hold Down" or Control Panel
J3 Audio Self Test disabled
J4 Auto PTT enabled
J5 Calls only allowed when Fire Panel is Active
J6 "Inactive" message enabled
NOTE: Fitting a jumper overides the relevant Tone Configuration option.
