3.2.4.2 Set Option Jumpers
If required, set the option jumpers to the required configuration.
These are shown as items "B" and "F" in
Figure 3.12.
The bold options in Table 3.6 show the factory preset settings.
Table 3.6 — BVOCRFC Jumper Settings
Table 3.7 — Tone Configuration Default Settings
JP # Status Option
J1 "Upper"
position
Unit can only be reset using the Keyswitch (see
note below)
J1 "Lower"
position
Reset option set by Tone Configuration (see note
below)
J2 Must NOT Be Fitted
J3 Fitted Audio Self Test Enabled
J3 Not Fitted Audio Self Test controlled by Tone Configuration
J4 Fitted Auto PTT for DRS Disabled
J4 Not Fitted Auto PTT for DRS conrolled by Tone
Configuration
J5 Fitted DRS calls always allowed
J5 Not Fitted DRS calls controlled by Tone Configuration
J6 Fitted Inhibit the DRS "Inactive Message"
J6 Not Fitted DRS "Inactive" message controlled by Tone
Configuration
NOTE: If it is required that the Remote Unit is reset using the keyswitch
only AND only allowed to make calls when the Fire Panel is Active then
this must be set using Tone Configuration and not using J1 and J5.
JP # Option
J1 Reset by either Keyswitch or Control Panel
J3 Audio Self Test disabled
J4 Auto PTT for DRS enabled
J5 DRS Calls only allowed when Fire Panel is Active
J6 DRS "Inactive" message enabled
NOTE: Fitting a jumper overides the relevant Tone Configuration option.
