R5917517 /00 ClickShare CB Core, CB Pro22

4.1 Methods of installing

Possible physical configurations

The Base Unit can be installed in multiple configurations:

• Standing on the wall mount. For more information, see “Install standing on its wall mount”, page 23

• Standing on a flat surface. For more information, see “Install standing on a flat surface”, page 23

• Mounted to a wall. For more information, see “Install mounted to the wall”, page 24

• Mounted as a part of the display with the optional display mount accessory. For more information, see

“Install as a part of the display”, page 25

For an optimal experience during use, keep the following in mind when choosing a location to install the Base

Unit:

• Install the Base Unit near to the display.

• Provide a clear line of sight to the rest of the meeting room.

• Do not install the Base Unit in a metal enclosure!

• Do not mount the Base Unit on the ceiling!

If accessibility of the connector side will be limited due to mounting, then connect the required

cables to the Base Unit first. For more information, see “Hardware connections”, page 26.

Possible network configurations

Depending on the type of meeting room, how the local network was setup or requirements that are needed,

different methods of integrating ClickShare into the network can be preferred. The possible methods are:

• Network connected setup. (default)

• Dedicated network connected setup.

For more information on how to configure the network configurations, see “Wi-Fi settings”, page 69

Installing CB Core, CB Pro
