Barco G62 Series - Page 61

61R5914654 /04 G62 series
4.1 About the UST lens.......................................................................................................................62
4.2 Lens rotation mechanics ...............................................................................................................63
4.3 Lens support installation................................................................................................................67
4.4 UST lens support adjustment.........................................................................................................71
UST sales kit
The sales kit contains:
• The UST lens
• The UST lens support
• Safety cable
The UST lens must always be mounted with the UST lens support and the safety cable.
UST lens R9801830
G lens (0.37 - 0.40 :
1) UST 90°
4
