1.2 General Specifications
Specification piA640-210gm/gc piA1000-48gm/gc piA1600-35gm/gc
Sensor Size
(H x V pixels)
gm: 648 x 488
gc: 646 x 486
gm: 1004 x 1004
gc: 1000 x 1000
gm: 1608 x 1208
gc: 1604 x 1204
Sensor Type Kodak KAI-0340M/CM Kodak KAI-1020M/CM Kodak KAI-2020M/CM
Progressive scan CCD
Optical Size 1/3" 2/3" 1"
Pixel Size 7.4 µm x 7.4 µm 7.4 µm x 7.4 µm 7.4 µm x 7.4 µm
Max. Frame Rate
(at full resolution)
210 fps 48 fps 35 fps
Mono/Color All models available in mono or color
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models: Mono 8 (equivalent to DCAM Mono 8)
Mono 16 (equivalent to DCAM Mono 16)
Mono 12 Packed
YUV 4:2:2 Packed (equivalent to DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
Color Models: Mono 8 (equivalent to DCAM Mono 8)
Bayer GB 8 (equivalent to DCAM Raw 8)
Bayer GB 16 (equivalent to DCAM Raw 16)
Bayer GB 12 Packed
YUV 4:2:2 Packed (equivalent to DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bits
Synchronization Via external trigger signal or via software
Exposure Control Programmable via the camera API
Camera Power
Requirements
+12 to +24 VDC, (min. +11.3 VDC, absolute max. +30.0 VDC ), < 1% ripple
4.5 W @ 12 VDC 4.2 W @ 12 VDC 4.8 W @ 12 VDC
I/O Ports 2 opto-isolated input ports and 4 opto-isolated output ports
Lens Adapter C-mount
