Specifications, Requirements, and Precautions
Basler pilot 11
1.4 Spectral Response for Color Cameras
The following graphs show the spectral response for each available color camera model.
Fig. 6: piA640-210gc Spectral Response
Note
The spectral response curves exclude lens characteristics, light source
characteristics, and IR cut filter characteristics.
To obtain best performance from color models of the camera, use of a
dielectric IR cut filter is recommended. The filter should transmit in a range
from 400 nm to 700 ... 720 nm, and it should cut off from 700 ... 720 nm to
1100 nm.
A suitable IR cut filter is included in the standard C-mount lens adapter on
color models of the camera. (An IR cut filter is not included in the optional CS-
mount adapter.)
