Basler pilot User Manual

Features
166 Basler pilot
11.7 Binning
Binning increases the camera’s response to light by summing the charges from adjacent pixels into
one pixel. Two types of binning are available: vertical binning and horizontal binning.
With vertical binning, adjacent pixels from 2 lines, 3 lines, or a maximum of 4 lines in the imaging
sensor array are summed and are reported out of the camera as a single pixel. Figure 45 illustrates
vertical binning.
Fig. 45: Vertical Binning
With horizontal binning, adjacent pixels from 2 columns, 3 columns, or a maximum of 4 columns are
summed and are reported out of the camera as a single pixel. Figure 46 illustrates horizontal bin-
ning.
Fig. 46: Horizontal Binning
Note
The binning feature is only available on the monochrome cameras.
Vertical Binning by 2 Vertical Binning by 3 Vertical Binning by 4
Horizontal Binning by 2 Horizontal Binning by 3 Horizontal Binning by 4
