Specifications, Requirements, and Precautions
20 Basler pilot
1.5.3 Maximum Thread Length on Color Cameras
The C-mount lens adapter on color models of the camera is normally equipped with an internal IR
cut filter. As shown below, the length of the threads on any lens you use with a color camera must
be less than 8.0 mm. If a lens with a longer thread length is used, the IR cut filter will be damaged
or destroyed and the camera will no longer operate.
Fig. 15: Maximum Lens Thread Length on Color Cameras
Note
C-mount color cameras that do not include an internal IR cut filter are available
on request.
Monochrome cameras are not normally equipped with an internal IR cut filter,
however, they can be equipped with an internal filter on request.
