Specifications, Requirements, and Precautions
Basler pilot 17
1.5.2 90° Head Housing
The camera housing conforms to protection class IP30 provided the lens mount is covered by a lens
or by the cap that is shipped with the camera.
1.5.2.1 Camera Dimensions and Mounting Points
In pilot cameras with the 90° head housing the camera’s direction of view is at right angle to the
direction of view of standard pilot cameras.
The cameras are manufactured with high precision. Planar, parallel, and angular sides guarantee
precise mounting with high repeatability.
The dimensions in millimeters for cameras with 90° head housing are as shown in Figure 13.
Camera housings are equipped with four mounting holes on the top and four mounting holes on the
bottom as shown in the drawings. In addition, there are four mounting holes in the front module (4x
M3; 4.5 mm deep).
Note
For optimum accuracy in the positioning of the camera's optical axis, we
recommend using the front module reference plane (see the figure in the
Sensor Positioning Accuracy section) as mounting surface.
