Basler pilot User Manual

I/O Control
138 Basler pilot
10.1.2 Using an Unassigned Input Line to Receive
a User Input Signal
You can use an unassigned input line to receive your own, user-generated input signal. The
electrical characteristics of your input signal must meet the requirements shown in the Physical
Interface section of this manual.
You can use the Line Status or Line Status All parameters to monitor the state of the input line that
is receiving the user-defined signal.
For more information about using the Line Status and Line Status All parameters, see
Section 10.3.1 on page 147 and Section 10.3.2 on page 147.
Note
The line assigned to receive the ExTrig input signal can’t be used to receive a
user-designed input signal.
