Specifications, Requirements, and Precautions
Basler pilot 5
Specification piA1900-32gm/gc
Size (L x W x H)
(standard housing) 86.7 mm x 44 mm x 29 mm (without lens adapter or connectors)
98.5 mm x 44 mm x 29 mm (with lens adapter and connectors)
(90° head housing) 104.7 mm x 44 mm x 29 mm (without front module or connectors)
110 mm x 44 mm x 41.8 mm (with front module and connectors)
Weight
(standard housing) ~ 220 g (typical)
(90° head housing) ~ 240 g (typical)
Conformity CE, FCC, GenICam, GigE Vision, IP30
Table 2: General Specifications
Note
The sensor characteristics of the piA1900-32gm/gc cameras do not entirely
conform to the quality standards generally adhered to by Basler. The sensitivity
to light for clusters of up to six contiguous pixels may deviate significantly from
the sensitivities of normal pixels.
