Basler pilot User Manual

Features
150 Basler pilot
.
.
If, for example, the piA640-210 gm/gc camera is set for a pixel data format that yields 8 bit effective
pixel depth (Mono 8, YUV 4:2:2 Packed, YUV 4:2:2 (YUYV) Packed):
 The Gain Raw All value can be set in a range from 0 to 500.
 The Gain Raw Tap 1 value can be set in a range from 0 to 500.
 The Gain Raw Tap 2 value can be set in a range from 0 to 500.
 The sum of the Gain Raw All setting plus the Gain Raw Tap 1 setting must be between 0
and 500 (inclusive).
 The sum of the Gain Raw All setting plus the Gain Raw Tap 2 setting must be between 0
and 500 (inclusive).
Gain Raw All Gain Raw Tap 1 Gain Raw Tap 2
Camera Model Min
Setting
Max
Setting
(8 bit
depth)
Max
Setting
(16 bit
depth)
Max
Setting
(8 bit
depth)
Max
Setting
(16 bit
depth)
Max
Setting
(8 bit
depth)
Max
Setting
(16 bit
depth)
piA640-210 0 500 400 500 400 500 400
piA1000-48 0 500 400 500 400 500 400
piA1600-35 0 500 400 500 400 500 400
piA1900-32 0 500 400 500 400 500 400
piA2400-12 0 500 400 500 400 500 400
piA2400-17 0 500 400 500 400 500 400
Table 15: Minimum and Maximum Allowed Gain Raw Settings
Gain Raw All + Gain Raw Tap 1 Gain Raw All + Gain Raw Tap 2
Camera Model Min
Setting
Max
Setting
(8 bit depth)
Max
Setting
(16 bit depth)
Max
Setting
(8 bit depth)
Max
Setting
(16 bit depth)
piA640-210 0 500 400 500 400
piA1000-48 0 500 400 500 400
piA1600-35 0 500 400 500 400
piA1900-32 0 500 400 500 400
piA2400-12 0 500 400 500 400
piA2400-17 0 500 400 500 400
Table 16: Minimum and Maximum Allowed Total Gain Settings
