Baum BAUMCUT 31.5 - Clamping, Cutting, and Pressure Settings

K4 - 3
1 2
3
4 5
6
7 8 9
C
0
x
D
i
PROGRAMMABLE
4.0 Manual Operation
4
5
Starting the cut:
Push both cut buttons (4) simultaneously.
(Hold buttons until knife is on upstroke)!
Interrupting the cut:
Release one or both cut buttons
(clamp and knife stop immediately and move back to initial position).
Continuing the cut:
Release and simultaneously push both cut buttons.
5
Clamp Pressure Adjustment
Turn knob (5) to desired position
Stepless adjustment - ranges of adjustment:
180 - 2700 daN (daN = kp)
Setting the Clamping Time
For bulky cutting material, it may be of advantage to set an extended clamping
time prior to cutting.
The clamping time is set via selection menu - refer to "Machine Parameter -
Select "Pre-clamping time"
Clamping and Cutting
180
500
1000
1500
2000
2500
2700
