K5D - 2
5.0 Automatic Operation
1. Select free program
2. Press key "Auxiliary Functions"
3. Select "Cut and record"
4. Make cut < actual size is stored upon every cut >
After program generation:
Switch function off by selecting it again (when program is changed
or "Automatic On" is activated function is switched off automatically!)
Cut and Record
Sheet Size Tables
List of DIN sizes A0 - A9.
The corresponding sizes (lengths or widths) can be selected by cursor and
transferred to the input section.
Procedure:
1. Press key
2. Select desired size (length or width) using cursor keys
3. Press key
< Value is transferred to the input section >
