Baum BAUMCUT 31.5 - Example: Setting Up Cutting Program 2

K5A - 16
5. 21,0 cm
4. 42,0 cm
1. 30,5 cm
3. 29,7 cm
2. 42,5 cm
5.0 Automatic Operation
Setting Up a Cutting Program, Example 2
Four edge trim with following cuts;
starting size DIN A3 untrimmed 31 x 43 cm;
finish size DIN A4 (21 x 29,7 cm)
Cut sizes:
1. 30,5 cm
2. 42,5 cm
3. 29,7 cm
4. 42.0 cm
5. 21,0 cm
Cut sizes to be stored in program 4A
Key input:
1. Call program 5A
2.
3.
4.
5.
6.
Program data display after key input:
