Drive Management
Parameter manual b maXX
®
1000
Document no. 5.07004.03
15
of 208
3
11 OPERATION ENABLED  QUICKSTOP ACTIVE
n Event:
m Command ’quickstop’ or
m Quickstop input = Low (default quickstop input MI5 = 23)
n Action:
m Quickstop function is activated
12 QUICKSTOP ACTIVE  INHIBIT START
n Event:
m Command ’inhibit voltage’ or
m Quickstop is stopped (speed 0 has been reached)
m Pulse enable input MI6 = Low
n Action:
m Drive operation is inhibited
13 All conditions  ERROR REACTION ACTIVE
n Event:
m Drive error is recognized
n Action:
m Error-dependable error reactions are activated
m Ready-to-operate relay is switched off (multi function relay)
14 ERROR REACTION ACTIVE  ERROR
n Event:
m Error reaction is completed
n Action:
m Drive operation is inhibited
15 ERROR  INHIBIT READY TO START
n Event:
m Command ’reset error’ or
m RESET ERROR input = Low → High (multi function digital input)
n Condition:
m Error doesn’t exist anymore
n Action:
m Reset error is carried out
16 QUICKSTOP ACTIVE  OPERATION ENABLED
n Event:
m Command ’operation enabled’
n Condition:
m Quickstop reaction (ZP1004– or ZP1009–) Quickstop reaction ( or is set to
’Remain in quickstop” (values 4 to 7) or
m Quickstop-input = High (default quickstop input MI5 = 23)
m Pulse enable input MI6 = High
n Action:
m Drive function is enabled again
