Baumuller b maXX BM4-O-CAN-03 User Manual

Installation
Instruction handbook CANopen slave BM4-O-CAN-03
Document no. 5.02014.06 Baumüller Nürnberg GmbH
30
of 68
5.5
5.5.2 Requirements on the electrical connection
CAUTION
The following may
occur, if you do not observe this caution information:
m pr
operty damage.
The hazard is: elect
rical voltage. In case you do not ensure the requirements to the electrical
connection, the plug-in module can be damaged/destroyed.
Assure, that the in the technical d
ata specified connection values are complied with and that
the connections are made according to the requirements of the CANopen field buses.
To achieve the standard EN 60 204-1 (electrical equipment of machines), you must use
th
e cables, which are recommended there. The connectors may not decrease - otherwise
the following dangers can arise - short circuits, interference voltages a. s. o.
h r
egard to EMC-compatible laying of the CANopen connection cables.
5.5.3 Requirements to the connection cables
The following cables are released for usage from Baumüller:
m CANop
en connection cable; further information is to be found in ZD.5 Cable connec-
tor– fro
m page 64.
5.5.4 Operating sequence of installation
1 assure that the b maXX-device is off-circuit.
2 take off t
he dust cover from the controller unit.
m The option
module CANopen slave is in slot H (preferred slot), see ZFigure 2– on
page 22.
3 con
nect the CANopen connection cables and accordingly the connection lines and ter-
minating resistor connectors (RJ45 connector), see ZB.
1 List of all accessories– on
page 59 with the plug-in module (outgoing cable downwards).
4 at
tach the dust cover to the device again.
5 ins
tall the lines according to the instructions into the switching cabinet.
