Instruction handbook CANopen slave BM4-O-CAN-03
Document no. 5.02014.06
APPENDIX C - TECHNICAL DATA
In this appendix you will find the technical data for the option module CANopen slave of the
company Baumüller Nürnberg GmbH.
D.1 Option module CANopen slave BM4-O-CAN-03
The plug-in module has the following specifications:
Baud rates 20/125/250/500/1000 kBit/s
Physical Layer ISO 11898
Electrical isolation Optocoupler, DC/DC-converter
Connectors 2 x RJ45 female connector
Power supply +5 V from controller supply
Current power 460 mA
Storage 4 kByte DP-RAM, 256 kByte RAM, 
1 MByte Flash-Eprom
Environmental condition According b maXX 4000
Storing condition According b maXX 4000
Transport condition According b maXX 4000
