Marking of the option module CANopen slave - type key
Instruction handbook CANopen slave BM4-O-CAN-03
Document no. 5.02014.06 Baumüller Nürnberg GmbH
24
of 68
4.3
4.3 Marking of the option module CANopen slave - type key
On the front sheet you will find a module identification („D“ in ZFigure 1– on page 19) and
the serial number („E“ in ZFigu
re 1– on page 19) of the plug-in module.
NOTE
This type key only applies to the option module CANo
pen slave of the series b maXX 4400.
Other plug-in modules have an own type key. Type key of the accessories see ZAccesso-
ries– fro
m page 59.
BM4 - O - CAN - xx - yy - zz Device generation, in which the plug-in module can
be build in
BM4 - O - CAN - xx - yy - zz Module type (option module)
BM4 - O - CAN - xx - yy - zz Plug-in module identification (CAN)
BM4 - O - CAN - xx - yy - zz Plug-in module version
03: CANopen slave
BM4 - O - CAN - xx - yy - zz Hardware version
00: Standard
BM4 - O - CAN - xx - yy - zz Software version
00: Standard
This type key you will find on the front side of the front sheet. The type key
includes the
basic data of the plug-in module. With the type key you will find further data in the chapter
„Technical Data“. A survey of all the technical data is to be found in ZAp
pendix C - Tech-
nical data– fr
om page 61.
