90 BD FACSCanto Flow Cytometer Reference Manual
5 Put a new level sensor assembly on the cubitainer or tank. Hand-tighten the
cap until it is fully closed.
6 Ensure use of the correct assembly (Figure 4-8).
Figure 4-8 Level sensor assemblies
7 Reattach the sensor line and fluidics lines.
8 If you replaced any level sensors (other than the waste sensor), prime the
affected fluidics lines.
Important: Continue with the procedure in Priming Fluidics Lines on
page 71.
To ensure that the appropriate solutions are dispensed, make sure the label
on the container matches the labeled port on the fluidics cart.
waste level sensor
(red connector)
BD FACSFlow level sensor
(blue connector)
BD FACSClean solution and
BD FACS shutdown solution
level sensor (green connector)
