Becker RT6201 Installation & Operation

AR6201 - RT6201 - RCU6201 - AR6203
DV 14307.03 Issue 1 09/2013 Page 2-33
Display Contents Description
SIDETON ATT
6
The s
idetone attenuation “SIDETONE ATT” is
adjustable within the range 0…12 dB by turning the
“ROTARY ENCODER”.
The attenuation relates to the intercom volume.
0dB = sidetone as loud as intercom signal.
12dB = sidetone signal 12dB less than the
intercom signal.
Example; If the intercom volume
is set to a very
low value, then the s
idetone volume will be reduced
in relation to the intercom volume, irrespective of
the sidetone value.
The “SIDETONE ATT”
parameter is an additional
attenuation of the sidetone signal in transmit
mode.
Note:
Menu available on primary controller only.
ERASE CHN MEM
YES
NO
The 620X Transceiver
provide two databases to store
up to 99 VHF frequencies identified by cha
nnel
numbers (CH01 to CH99).
Both data bases
, the “User Channels Database” and
“Last Channels Database” can be erased.
To erase the data bases;
1. Select “YES” via the “ROTARY ENCODER”
2. Press the “STO” push-
button to confirm the
selection.
Note:
Menu available on primary controller only
ERASE FREQ LAB
YES
NO
The AR6201-(XX
X) provides a third database,
“FRQUENCY LABELS DATABASE”, containing 99 text
labels of max 10 characters each. A text label can
be assigned to any of the channels (CH01 to C
H99),
the Labels are stored manually.
The “LABELS DATABASE” can be erased.
To Erase the data base;
1. Select “YES” via the “ROTARY ENCODER”
2. Press the “STO” push-
button to confirm the
selection.
Note:
Menu available on primary controller only
