Beckhoff EP31 Series User Manual

Product overview
EP31xx 15Version: 2.4
2.3.2 EP3162 - Technical data
Technical data EP3162-0002
Fieldbus
Fieldbus EtherCAT
Connection 2x M8 socket, green
Electrical isolation 500V (fieldbus/ IO)
Distributed Clocks Yes
Supply voltages
Connection Feed: 1 x M8 plug, 4-pin, black
Downstream connection: 1 x M8 socket, 4-pin, black
Control voltage U
S
Nominal voltage 24V
DC
(-15%/ +20%)
Sum current max. 4A
1)
Consumers • Module electronics: 120mA
• Sensors
2)
Peripheral voltage U
P
Nominal voltage 24V
DC
(-15%/ +20%)
Sum current max. 4A
1)
Consumers None. U
P
is only forwarded.
Analog inputs
Number 2
Connection 2x M12 socket, 5-pin
Input type Single-ended
Signal range Parameterizable:
• -10.. +10V (default)
• 0.. 10V
• 0.. 20mA
• 4.. 20mA
• -20.. +20mA
Digital resolution 16-bit, including sign
Measuring error max 0.3%, relative to the full scale value
Input resistance Voltage measurement: min. 200kΩ
Current measurement: 85Ω + diode voltage
Dielectric strength max. 30V
Electrical isolation 300V between the input channels
Conversion time approx. 100µs
Input filter limit frequency 5kHz
Input filter characteristic
Parameterizable [}82]
Sensor supply voltage U
A
3)
24V
DC
, isolated potential.
Output current per channel:
max. continuous current 50mA
max. peak current 100mA
1)
Sum current of consumers and power transmission. This value corresponds to the
current carrying capacity of the connections for the supply voltages.
2)
"Sensors": devices connected to the input connections.
3)
Supply voltage available at the input connections.
