Configuration
EP31xx 109Version: 2.4
4.17 EP31x2 - Object description and parameterization
EtherCAT XML Device Description
The display matches that of the CoE objects from the EtherCAT XML Device Description. We rec-
ommend downloading the latest XML file from the download area of the Beckhoff website and in-
stalling it according to installation instructions.
Parameterization via the CoE list (CAN over EtherCAT)
The EtherCAT device is parameterized via the CoE - Online tab [}60] (double-click on the respec-
tive object) or via the Process Data [}57] tab (allocation of PDOs).
Introduction
The CoE overview contains objects for different intended applications:
• Objects required for parameterization [}109] during commissioning
• Objects for indicating internal settings [}112] (may be fixed)
• Further profile-specific objects [}120] indicating inputs, outputs and status information
The following section first describes the objects required for normal operation, followed by a complete
overview of missing objects.
Objects to be parameterized during commissioning
Index 1011 Restore default parameters
Index (hex) Name Meaning Data type Flags Default
1011:0 Restore default parame-
ters
Restore default settings UINT8 RO 0x01 (1
dec
)
1011:01 SubIndex 001 If this object is set to "0x64616F6C" in the Set Value
Dialog, all backup objects are reset to their delivery
state.
UINT32 RW 0x00000000
(0
dec
)
