Beckhoff EP31 Series User Manual

Product overview
EP31xx20 Version: 2.4
Technical data EP3182-1002
Digital outputs
Number 2
Connection M12 sockets of the analog inputs
Nominal voltage 24V
DC
from peripheral voltage U
P
Output current I
OUT
2mA per output, short-circuit proof
Internal resistance approx. 2350Ω (high level)
Impedance of connected inputs min. 10kΩ
Environmental conditions
Ambient temperature
during operation
0 .. +55°C
Ambient temperature
during storage
-40.. +85°C
Vibration / shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP65, IP66, IP67 (conforms to EN 60529)
Mechanics
Weight approx. 165g
Installation position variable
Approvals and conformity
Approvals CE, cURus
