Chapter 5 Operator Interface/Wash Setup Screens
Setup
SETUP / MISC
Misc (first screen)
• Enter Wind Door Output: From this screen you can choose the state of the Output when the wash requests
the Wind Door to open. The options are “ON for Open” or “OFF for Open”
• ON for Open: will close the Wind Door when the power goes down, possibly striking a vehicle. NO
EXCEPTIONS!!
• OFF for Open: will open the Wind Door when the power goes down, possibly freezing the bay. Note
during an “E-Stop” condition the power is off
Typically Wind Door will be open when vehicle is entered into Queue and will remain open until vehicle gets
through Bay-Enter Photo Eye.
• Prep Jet Off Delay: This displays how many seconds the Prep Jet will remain ON after the Prep Jet input
has turned OFF.
• Set the time low when using a sensor activation unit.
• Set the time high when using a Push Button activation unit.
If this input is left ON for longer than 720 seconds, the system will automatically shut the Prep Jet down.
• Truck / Van Photo Delay: The time period that Input will be OFF (brake of a Photo Eye) before the vehicle is
considered a truck or a van. Set to 0 (zero) to disable.
• Tire Sensor Location: This is the position of the Tire Sensor relative to the Bay Enter Photo-Eye. Positive
inches are for location after Bay Enter Photo-Eye. Negative inches are for location before Bay Enter Photo-
Eye. The sensor should be within +/- 12 inches of the Bay Enter Photo-Eye. This works with the functions
NAMED 19, 20, 45 and 46.
• Tire Sensor N.O. / N.C.: N.O. (Normally Open) is for a sensor that turns ON an input when the tire is
sensed. N.C. (Normally Close) is for a sensor that turns OFF an input when the tire is sensed.
