QUICKFIRE® WRAP AROUND
1MANUL825 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 11
Specifications
Dimensions
Tunnel Placement Overview
The placement images shown in this document are all laid out with the passenger side Stand closer to
the entrance of the tunnel. However, the most important factor is that the two Stands are off-set 78-1/2”
as far as tunnel depth. This means if your site is better suited with the driver side Stand closest to the
tunnel entrance, be sure to adhere to the stated off-set as shown in the diagrams.
Side View
121"
Entrance View
153"
204”
Operating Envelope
Direction of Travel
78-1/2"
190”
Minimum
