QUICKFIRE® WRAP AROUND
54 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL825
Initial Startup
Wheel Speed
1) Adjust the hydraulic flow control for a wheel speed between 88 – 96 RPM for Neo-Tex while under
vehicle load with the hydraulic pressure set at 900 to 1100 PSI
2) Insure that the wheel rotation direction is correct.
• Passenger side: clockwise
• Driver side: counter-clockwise
Air Settings
• Boom Pressure Regulator: 25PSI
• Head Pressure regulator: 40PSI
Make adjustments after running vehicles.
Note: After hubs and Cleaning materials have been installed, confirm that the
Booms remain level through their swing. If not, adjust as needed.
Note: The Sizer may require fine-adjusting at this time. More information on the
following pages.
Decrease air pressure if
more mirror clearance is
required
To Next Page
