QUICKFIRE® WRAP AROUND
44 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL825
Installation
Utility Connections for Side Wheels: Hydraulic
Understanding Hydraulic Wheel Rotation
The following will explain the factors that determine wheel rotation. Failure to understand these
factors can result in equipment or vehicle damage.
Rotation Direction:
• Driver side: counter clockwise
• Passenger side: clockwise
CAUTION
All utilities MUST be installed in accordance with all local and national codes.
It is imperative that no foreign materials are in the supply lines before final connections are
made. To be sure of this, the lines should be blown out prior to final hookup.
It is recommended that licensed technicians are contracted to perform all utility installations.
Feed for counter-
clockwise rotation
(Driver Side)
RETURN
Feed for
clockwise rotation
(Passenger Side)
FEED FEED
RETURN
Return
Feed
Driver Side Direction of Travel
Feed
Passenger Side Direction of Travel
Return
