Belanger QuickFire - Neo-Tex with Nylon Brush Fill Replacement

QUICKFIRE® WRAP AROUND
1MANUL825 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 93
Maintenance
Neo-Tex® with Nylon Brush Fill Replacement
Entrance Wheel
1PLSTC-CL025 (8” Wash Clip) 1PLSTC-CL050 (10” Wash Clip)
Entrance Wheel Neo-Tex® Fill Pattern
Overhead View of
Upper Hub Fill
Pattern
(6” diameter hub)
Fill slots as shown
Overhead View of
Lower Hub Fill
Pattern
(12” diameter hub)
Fill every other slot as shown
Upper
Middle
(Accent
Color)
Lower
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
33” x 8” x 1/8” thick
6215 6216 6218 6217 7407 6384
EXTRA CLIPS PROVIDED FOR THIS ROW TO FILL ALL EMPTY SLOTS
BLACK ONLY
1 piece:
18” x 12” Nylon
Brush
1BRUSH130
THIS ROW HAS
EVERY SLOT
FILLED
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
33” x 8” x 1/8” thick
6215 6216 6218 6217 7407 6384
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
41” x 8” x 1/8” thick
6227 6228 6230 6229 7410 6393
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
25” x 8” x 1/8” thick
6338 6339 6341 6340 7413 6402
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
25” x 8” x 1/4” thick
7112 6800 6797 7633 7634 7635
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
28” x 8” x 1/4” thick
7113 6801 6798 7636 7637 7638
BLACK BLUE RED GREEN ORANGE YELLOW
1 piece:
32” x 10” x 1/4” thick
7114 7685 7003 7639 7640 7641
