QUICKFIRE® WRAP AROUND
1MANUL825 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 65
Maintenance
General Replacement Information
Spherical Bearing Replacement Tip
Note: Whenever replacing the Hydraulic Motor, Four-Bolt bearings, the or making any
adjustments to the Torque Plate be sure not to over tighten the long bolts. Doing so may
damage or crack the bearing as shown below.
When tightening the long bolts on the Spherical Bearing, tighten until the bolt barely touches the bearing using
Loctite® 271. Over tightening may damage or crack the bearing. Tighten all four jam nuts to 85 foot/pounds
using Loctite® 271.
Torque Plate
Spherical Bearing
Jam Nut
(typical)
