QUICKFIRE® WRAP AROUND
82 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL825
Maintenance
Replacement Parts
Head Assembly: Hydraulic
7069 7096 1FSTNR-SH472 1FSTNR-FH842 7066 7067
3626
1WASHR-LC498 (16)
7096
7038 (2)
3625
7067 (4)
1FSTNR-HH540 (16)
7069
7068
7070
7071
1WASHR—LC498 (4)
7083 (2)
1FSTNR—SH472 (8)
7066 (4)
1FSTNR-HH540 (2):
Apply Loctite® 271 and
tighten to 55 ft/lb
1FSTNR-FH842 (4):
Apply Loctite® 271 and
tighten to 55 ft/lb
1FSTNR—HH571 (2):
Apply Loctite® 271 and
tighten to 55 ft/lb
7095
7094
1FSTNR-HH198 (4)
1WASHR-LC270 (4)
