Benelli 502C User Manual

6 - 19
Periodic maintenance and adjustment
EN
6
the clutch screw anticlockwise (seen from
sitting on the bike).
3) After adjusting, tighten the clutch ring
nut.
1. Clutch ring nut
2. Clutch screw
TIP
If the specied free play cannot be obtai-
ned as described above or if the clutch
does not operate correctly, have a Benelli
dealer check the internal clutch mechani-
sm.
Checking the brake lever free play
There should be no free play at the brake
lever end. If there is free play, have a Be-
nelli dealer inspect the brake system.
WARNING
A soft or spongy feeling in the brake
lever can indicate the presence of air
in the hydraulic system. If there is air in
the hydraulic system, have a Benelli de-
aler bleed the system before operating
the vehicle. Air in the hydraulic system
will diminish the braking performance,
which may result in loss of control and
an accident.
Brake light switches
The brake light, which is activated by the
brake pedal and brake lever, should come
on just before braking takes eect.
If necessary, have a Benelli dealer adjust
the brake light switches.
2
1

Benelli 502C Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	21 liters
Rear Brake	Single disc
Seat Height	750 mm
Curb Weight	217 kg
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Max Power	47.6 hp @ 8, 500 rpm
Max Torque	45 Nm @ 6, 000 rpm
Front Suspension	Upside-down forks
Front Brake	Double Discs
Wheelbase	1600 mm
Fuel System	EFI
Rear Suspension	Swingarm with monoshock
