Benelli 502C User Manual

6 - 33
Periodic maintenance and adjustment
EN
6
Troubleshooting charts
Starting problems or poor engine performance
Check the fuel level in
the fuel tank.
1. Fuel
There is enough fuel.
There is no fuel.
Check the battery.
Supply fuel.
The engine does not start.
Check the battery.
Remove the spark plugs
and check the electrodes.
3. Ignition
spark plug gaps, or replace the spark plugs.
Have a Benelli dealer check the vehicle.
Operate the electric starter.
4. Compression
There is compression.
There is no compression.
The engine does not start.
Have a Benelli dealer check the vehicle.
Have a Benelli dealer check the vehicle.
The engine does not start.
Check the compression.
Operate the electric starter.
2. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The engine does not start.
Check the ignition.
The battery is good.
Check the battery lead connections,
and have a Benelli dealer charge
the battery if necessary.
Dry
Wet
Operate the electric starter.

Benelli 502C Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	21 liters
Rear Brake	Single disc
Seat Height	750 mm
Curb Weight	217 kg
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Max Power	47.6 hp @ 8, 500 rpm
Max Torque	45 Nm @ 6, 000 rpm
Front Suspension	Upside-down forks
Front Brake	Double Discs
Wheelbase	1600 mm
Fuel System	EFI
Rear Suspension	Swingarm with monoshock
