Benelli 502C User Manual

9 - 2
Consumer information
EN
9
Model label
The label of the model is applied to
the left side of the steering head.
Record the information on this label
in the space provided. This informa-
tion will be needed when ordering
spare parts from a Benelli dealer.
WARNING
Any changes to the ID number stamped
on the frame or engine will automati-
cally render the warranty null and void.
Diagnostic connector
The diagnostic connector is located as
shown.
B-Box connector
The B-Box device, where it is available, can
be connected via the connector in the
gure, collects and sends data relating
to GPS tracking , as route traveled, speed,
distance, travel time, etc. visible through
the “MyBenelli” app.

Benelli 502C Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	21 liters
Rear Brake	Single disc
Seat Height	750 mm
Curb Weight	217 kg
Engine Type	Liquid-cooled, 4-stroke, 2-cylinder
Max Power	47.6 hp @ 8, 500 rpm
Max Torque	45 Nm @ 6, 000 rpm
Front Suspension	Upside-down forks
Front Brake	Double Discs
Wheelbase	1600 mm
Fuel System	EFI
Rear Suspension	Swingarm with monoshock
