6 - 10
Periodic maintenance and adjustment
EN
6
Canister
This model is equipped with a canister to
prevent the discharging of fuel vapor into
the atmosphere. Before operating this
vehicle, make sure to check the following:
• Check each hose connection.
• Check each hose and canister for
cracks or damage. Replace if dama-
ged.
Engine oil and oil lter cartridge
The engine oil level should be checked
before each ride. In addition, the oil must
be changed at the intervals specied in
the periodic maintenance and lubrication
chart.
To check the engine oil level
1. Place the vehicle on a at surface and
keep it upright. A slight tilt to the side can
result in a false reading.
2. Start the engine, warm it up for several
minutes, and then turn it o.
3. Wait a few minutes until the oil settles,
and then check the oil level through the
engine oil level check window located at
the bottom-right side of the crankcase.
TIP
The engine oil should be between the mi-
nimum and maximum level marks.
4. If the engine oil is below the minimum
level mark, add sucient oil of the recom-
mended type to raise it to the correct le-
vel.
1. Engine oil cap
1. Engine oil level check window.
2. Maximum level mark.
3. Minimum level mark.
2
3
H
L
1
1
1
