Benelli 502C - Description; Laterals View

Description
EN
2
2 - 2
Lateral view
1) Front light.
2) Front position indicators.
3) Rear position indicators.
4) Footrest.
5) Rear-view mirrors.
6) Saddle.
7) Rear brake light.
8) Side stand.
9) Rear brake disc.
10) Gearbox pedal.
11) Fuel tank.
12) Exhaust manifolds.
13) Front brake disc.
14) Dashboard.
15) Engine oil inspection port.
16) Rear brake pedal.
17) Passenger pedals.
18) Fuel tank cap.
19) Ignition switch.
20) Rear shock absorber.
21) Saddle lock.
