USB-A
USB-C
a
b
c
d
Speakers
USB peripherals
Computer / gaming console / AV device
Certified devices with USB-C port
which supports DP Alt Mode
Wireless AP
Computer /mobile device /
AV device
No. Descriptions No. Descriptions
a.
USB flash drive for media reader
and peripherals
c.
Certified PD Alt mode USB-C
cable
b.
HDMI cable
d.
Audio cable
Note
• In the connections above, some cables may not be included with the projector (see "Package con-
tents" on page 17). They are commercially available from stores.
• The connection illustrations are for reference only.
• If the selected video image is not displayed after the projector is turned on and the correct video
source has been selected, check that the video source device is turned on and operating correctly.
Also check that the signal cables have been connected correctly.
• The built-in speaker(s) will be muted when the AUDIO OUT jack is connected.
