Timing chart
Resolution Mode
Vertical
frequency
(Hz)
Horizontal
frequency
(KHz)
Dot Clock
Frequency
(MHz)
640 x 480 VGA_60 59.94 31.469 25.175
720 x 400 720x400_70 70.087 31.469 28.3221
800 x 600 SVGA_60 60.317 37.879 40
1024 x 768 XGA_60 60.004 48.363 65
1280x720 1280 x 720_60 60 45 74.25
1280 x 768 1280 x 768_60 59.87 47.776 79.5
1280 x 800 WXGA_60 59.81 49.702 83.5
1280 x 1024 SXGA_60 60.02 63.981 108
1280 x 960 1280 x 960_60 60 60 108
1440 x 900 WXGA+_60 59.887 55.935 106.5
1400X1050 SXGA+_60 59.978 65.317 121.75
1600x1200 UXGA 60 75 162
1680x1050 1680x1050_60 59.954 65.29 146.25
1920x1080@60HZ
1920X1080_60
(CEA-861)
60 67.5 148.5
1920X1080(VESA)
1920X1080_60
(for Auditorium model)
59.963 67.158 173
2560x1440@60HZ 2560X1440_60 59.951 88.787 241.5
2560x1600
(VESA)
2560X1600_60 59.987 99.458 348.5
3840x2160
3840x2160_30
(For 4K/2K model)
30 67.5 297
3840x2160
3840x2160_60
(For 4K/2K model)
60 135 594
Note
• USB-C port for alt mode supports up to 1920X1080@60Hz.
• Not all timings are available to the input source connected to the internal HDMI port. See "Video
timings" on page 74 for available timings.
