OSD Menu72
Tiling
Example: 2 x 2 screen matrix (4 displays)
H monitors = 2 displays
V monitors = 2 displays
H monitors
V monitors
Position
1 2
3 4
Example: 5 x 5 screen matrix (25 displays)
H monitors = 5 displays
V monitors = 5 displays
1 2
6 7
3 4
8 9
5
10
11 12 13 14 15
16 17 18 19 20
21 22 23 24 25
H monitors
V monitors
Position
• H monitors - Select the number of displays on the horizontal
side.
• V monitors - Select the number of displays on the vertical side.
• Position - Select the position of this display in the screen
matrix.
• Frame comp. - Choose to turn the frame compensation
function on or off. If selected Yes, the display will adjust the
image to compensate for the width of the display bezels in order
to accurately display the imag
• Enable - Choose to enable or disable the Tiling function. If
enabled, the display will apply the settings in H monitors, V
monitors, Position, and Frame comp..
• Switch on delay - Set the power-on delaying time (in
seconds).
The default option Auto allows a sequential powering-on for
each display by their ID number when multiple displays are
connected.
The options are: Off/Auto/2-255
