210
APPENDIX F - PARAMETER TABLES
LED LCD Parameter Setting Range Units Default Page Setting
P52 I/O 05
R1 Configuration
OFF: Off
FLFS: Fault (fail safe)
FLnF: Fault (non fail
safe)
run: Running
utS: UTS
AL: Alarm
rdyr: Ready
LOC: Locked Out
OC: Over Current
UC: Under Current
OLA: OL Alarm
ShFS: Shunt Trip (fail
safe)
ShnF: Shunt Trip
(non fail safe)
GfLt: Ground Fault
ES: Energy Saver
HEAt: Heating
SSpd: Slow Speed
SS F: Slow Speed
Forward
SS r: Slow Speed
Reverse
dcb: DC Braking
FAn: Cooling Fan
Fault FS
112
P53 I/O 06
R2 Configuration
Off
P54 I/O 07
R3 Configuration
Off
P55 I/O 08 Analog Input Trip Type
OFF: Disabled
Lo: Low Level
Hi: High Level
Off 113
P56 I/O 09 Analog Input Trip Level 0 – 100 % 50 114
P57 I/O 10 Analog Input Trip Time 0.1 – 90.0 Seconds 0.1 114
P58 I/O 11 Analog Input Span 1 – 100 % 100 115
P59 I/O 12 Analog Input Offset 0 – 99 % 0 116
P60 I/O 13 Analog Output Function
0: OFF (no output)
1: 0 – 100% Curr
2: 0 – 200% Curr
3: 0 – 800% Curr
4: 0 – 150% Volt
5: 0 – 150% OL
6: 0 – 10 kW
7: 0 – 100 kW
8: 0 – 1 MW
9: 0 – 10 MW
10: 0 – 100% Ain
11: 0 – 100% Firing
12: Calibration
Off 116
P61 I/O 14 Analog Output Span 1 – 125 % 100 117
P62 I/O 15 Analog Output Offset 0 – 99 % 0 117
P63 I/O 16 Inline Configuration Off, 1.0 – 10.0 Seconds 3.0 118
P64 I/O 17 Bypass Feedback Time Off, 0.1 – 5.0 Seconds 2.0 118
P65 I/O 18 Keypad Stop Disable Enabled, Disabled Enabled 119
P66 I/O 19 Power on Start Selection
0: Disabled
1: Start after Power
applied only
2: Start after Fault reset
only
3: Start after power
applied and after
fault reset.
Disabled 119
