Function Group
211
APPENDIX F - PARAMETER TABLES
LED LCD Parameter Setting Range Units Default Page Setting
P79 FUN 01 Meter 1
0: Status
1: Ave Current
2: L1 Current
3: L2 Current
4: L3 Current
5: Curr Imbal
6: Residual Ground
Fault
7: Ave Volts
8: L1-L2 Volts
9: L2-L3 Volts
10: L3-L1 Volts
11: Overload
12: Power Factor
13: Watts
14: VA
15: vars
16: kW hours
17: MW hours
18: Phase Order
19: Line Freq
20: Analog Input
21: Analog Output
22: Run Days
23: Run Hours
24: Starts
25: TruTorque %
26: Power %
27: Peak Starting
Current
28: Last Starting
Duration
Ave Current 127
FUN 02 Meter 2 Ave Volts 127
P78 FUN 03 CT Ratio
72:1, 96:1,144:1, 288:1,
864:1, 2640:1, 3900:1,
5760:1, 8000:1, 14400:1,
28800:1
288 126
P77 FUN 04 Input Phase Sensitivity
InS Insensitive
AbC ABC
CbA CBA
SPH Single Phase
Insens. 126
P76 FUN 05 Rated RMS Voltage
100, 110, 120, 200, 208,
220, 230, 240, 350, 380,
400, 415, 440, 460, 480,
500, 525, 575, 600, 660,
690, 800, 1000, 1140,
RMS
Voltage
480 125
P75 FUN 06 Motor Rated Power Factor -0.01 (Lag) – 1.00 (Unity) -0.92 125
P74 FUN 07 Starter Type
nor: Normal
Id: Inside Delta
y-d: Wye-Delta / Other
Electro
mechanical
PctL: Phase Control
cFol: Current
Follower
AtL: Full Voltage ATL
Normal 124
P73 FUN 08 Heater Level Off, 1 – 40 %FLA Off 123
P72 FUN 09 Energy Saver Off, On Off 122
P70 FUN 10 Communication Address 1 – 247 1 121
P69 FUN 11 Communication Baud Rate
1200
2400
4800
9600
19200
bps 19200 121
P68 FUN 12 Communication Timeout Off, 1 – 120 Seconds Off 121
