64
5 - PARAMETER GROUPS
Number Parameter Setting Range Units Default Page
P60 Analog Output Function
0: Off (no output)
1: 0 – 100% Curr
2: 0 – 200% Curr
3: 0 – 800% Curr
4: 0 – 150% Volt
5: 0 – 150% OL
6: 0 – 10 kW
7: 0 – 100 kW
8: 0 – 1 MW
9: 0 – 10 MW
10: 0 – 100% Ain
11: 0 – 100% Firing
12: Calibration
0: Off
(no output)
116
P61 Analog Output Span 1 – 125 % 100 117
P62 Analog Output Offset 0 – 99 % 0 117
P63 Inline Configuration Off, 1.0– 10.0 Seconds 3.0 118
P64 Bypass Feedback Time Off, 0.1 – 5.0 Seconds 2.0 118
P65 Keypad Stop Disable On, OFF On 119
P66 Power On Start Selection
0: Disabled
1: Start after power applied
only
2: Start after fault reset only
3: Start after power applied
and after fault reset
0 119
P67 Miscellaneous Commands
0: None
1: Std. BIST
2: Powered BIST
3: Reset Run Time
4: Reset KWh/MWh
5: Enter Reflash mode
6: Store Parameters
7: Load Parameters
8: Factory Reset
0 120
P68 Communication Timeout Off, 1 – 120 Seconds Off 121
P69 Communication Baud Rate
1200, 2400, 4800, 9600,
19200
bps 19.2 121
P70 Communication Address 1 – 247 1 121
P71 Communication Byte Framing
0: Even Parity, 1 Stop Bit
1: Odd Parity, 1 Stop Bit
2: No Parity, 1 Stop Bit
3: No Parity, 2 Stop Bits
0 122
P72 Energy Saver Off, On Off 122
P73 Heater Level Off, 1 – 40 %FLA Off 123
P74 Starter Type
nor: Normal
Id: Inside Delta
y-d: Wye-Delta / Other
Electro mechanical
PctL: Phase Control
cFol: Current Follow
AtL: Full Voltage ATL
nor 124
P75 Rated Power Factor -0.01 (Lag) to 1.00 (Unity) -0.92 125
P76 Rated Voltage
100, 110, 120, 200, 208, 220,
230, 240, 350, 380, 400, 415,
440, 460, 480, 500, 525, 575,
600, 660, 690, 800, 1000,
1140
RMS Voltage 480 125
P77 Phase Order
InS: Insensitive
AbC: ABC
CbA: CBA
SPH: Single Phase
InS 126
