Beretta IDRABALCONY Lx 11 User Manual

31
ENGLISH
Models 11-13
103
81 81
91
F
E
Fig. 15
Models 17
89
80
Fig. 16
Thegureshowsatopviewoftheboilerwiththereferencemeasure-
ments
fortheuegasexhaustandcombustionairinletcentre-to-centre
distances with respect to the boiler support plate.
Models 11-13
72 135 72 61
174
120
184
Fig. 17
Models 17
200 98 102
81
Fig. 18
3.4.2 Models for outdoor installation
For information on evacuating the products of combustion, please refer
to UNI 7129.
TheapplianceistypeA2andthereforehasnopipesfordischargingue
gases or a suction line for combustion air.
The combustion gases are expelled directly into the air by the integrated
outlet.
Fig. 19
a
Avoid inhaling combustion gases.
a
Avoid direct contact with the combustion gases since they can
reach extremely high temperatures that can cause burns.
a
Avoid direct contact with the discharge since it can reach extremely
high temperatures that can cause burns.
a
To ensure the combustion gases are expelled correctly, it is forbid-
den
toobstructorcover(evenjustpartially)thedischargeoutlet.
a
It is forbidden to loiter near the appliance when it is operating.
