BestCode NExT 88SHS - Venturi Replacement

BestCode Next Series 8 Technical Manual October 2022 Page 99 of 290
4. Push the SmartFill antenna coax cable
grommet through the middle
controller wall and remove the
SmartFill cup from the machine.
Venturi Replacement
Be familiar with proper safety information for handling fluids.
Procedure Time: 5 minutes
1. Remove SmartFill Ink Cup and Ink tank
2. Remove the Venturi inlet tube
3. Remove the venturi from the Ink Tank
and place it into a beaker.
