Flow tests for troubleshooting
Venturi Testing
The venturi function can be tested using the Software feature for Test Add Makeup. A failure of the Add Makeup Test may
indicate that the venturi is clogged, worn, or improperly tuned. Adjust or replace as necessary.
Performs a volume test for determining if the Venturi is able to meet Makeup Consumption requirements.
Note: This test is to be performed while the printer is running.
Step 1:
Measure out 50 to 100ml of makeup from the Makeup
Tank and put it into a graduated beaker
Step 2:
Put the Orange Makeup Tank
pickup into the beaker.
