BestCode Next Series 8 Technical Manual October 2022 Page 135 of 290

4. Confirm jet placement

MAGNIFIED GUTTER VIEW

Drop Generator Replacement

Be familiar with proper safety information for handling fluids.

Procedure Time: 5 minutes

1. Remove the 2 drop generator side

mounting screws

Perfect jet

alignment
