BestCode Next Series 8 Technical Manual October 2022 Page 277 of 290
Appendix F - System Cooling Types and Environmental Management Advice
Environment Selection
The installation environment is an important factor in selecting the correct machine to install.
88SHS, 88SHSOP, 88SM,
88SHS1, 88SOPHS1
Controller system add-ons
Controller is made from 316 Stainless for greater corrosion resistance
System runs on compressed air and prevents all dust and water from entering into the
electronics area of the cabinet. Includes air drier attached to system.
Add on air pump for prevent dust, dirt, or water build up in the printhead.
88SHS, 88SHS1,
88SHSOP,
88SOPHS1
Printing on bottom of product
Character height less than 0.05”
Print distance greater than ¼”
Longer distance from head to
controller
Dusty, Dirty, or Wet Conveyor
Printhead L-shape to allow extra mounting clearance.
Increased nozzle size. Travels farther and prints darker.
Extra length on the umbilical. Allows head to be mounted farther from the controller.
Cooling system runs on compressed air and prevents all dust and water from entering into the
electronics area of the cabinet. Includes air drier attached to system.
Add on air pump for prevent dust, dirt, or water build up in the printhead.
