BestCode NExT 88SHS - Pump Replacement

BestCode Next Series 8 Technical Manual October 2022 Page 103 of 290
Pump Replacement
Be familiar with proper safety information for handling fluids.
Procedure Time: 5 minutes
1. Remove the Makeup SmartFill Cup
2. Disconnect the Pump connector
from the main circuit board and
push the connector through the
middle bulkhead.
3. Locate and remove the 2 Pump
mounting screws.
4. Remove the pump from the back
of the machine and disconnect the
tubes.
