BestCode Next Series 8 Technical Manual October 2022 Page 136 of 290
2. Remove the black heat shrink over
the blue coax cable.
3. Remove the Yellow tube from the
Drop generator and the Drop
generator feed tube from the Valve
Manifold.
4. Remove the drop generator
5. Cut back half of the swaged yellow
tube.
Failure to steps 5-8 will
result in leaks from the
barb and tube.
Before Cutting
Cut location
